Basic Info.
Model NO.
Home Appliance Shaft
Roughness
Ra0.05
Straightness
0.005mm
Hardness
HRC/Hv
Length
2mm-1000mm
Transport Package
Plastic Bags Inside and Standard Cartons Outside.
Specification
Non-standard
Trademark
N/A
Origin
Ningbo, Zhejiang
HS Code
848310900
Production Capacity
3000000 Piece/Pieces / Month
Product Description
| No. | Item | Specifications |
| 1 | Materials | Carbon steel: 10#, 18#, 1018, 22#, 1022, 40Cr, 45#, 1045, 50#, 55#, 60#, 65Mn, 70#, 72B, 80#, 82B Alloy Structure Steel: B7, 20CrMo, 42Crmo, SCM415, SCM440, 4140 High-carbon chromium bearing steel: GCr15, 52100, SUJ2 Free-cutting steel: 12L14, 12L15 Stainless steel: 1Cr13, 2Cr13, 3Cr13, 4Cr13, 1Cr17, SUS410, SUS420, SUS430, SUS416, SUS440C, 17-4, 17-4PH, 130M, 200, 201, 202, 205, 303, 303Cu, 304, 316, 316L Aluminum grade: 6061, 6063 Brass: Hpb58-2.5 (C38000), Hpb59-1 (C37710), Hpb61-1 (C37100), Hpb62-0.8 (C35000), Hpb63-0.1 (C34900), Hpb63-3 (C34500), H60, H62, H63, H65 |
| 2 | Diameter | Ø0.3-Ø25 |
| 3 | Diameter tolerance | 0.002mm |
| 4 | Roundness | 0.0005mm |
| 5 | Roughness | Ra0.05 |
| 6 | Straightness | 0.005mm |
| 7 | Hardness: | HRC/HV |
| 8 | Length | 2mm-1000mm |
| 9 | Heat treatment | 1. Oil Quenching 2. High frequency quenching 3. Carburization 4. Vacuum Heat treatment 5. Mesh belt furnace heat treatment |
| 10 | Surface treatment | 1. Plating nickel 2. Plating zinc 3. Plating passivation 4. Plating phosphating 5. Black coating 6. Anodized treatment |
| 11 | Packing | Plastic bags inside and standard cartons outside. Shipment by pallets or according to customer's packing specifications. |
Q: How can I get samples? A: Free samples and freight collect, except for special circumstances.
Q: What is your minimum order quantity for the items in the order?
A: 2000pcs for each part except for sample.
Q: Are you a trading company or a manufacturer?
A: We are a manufacturer, specialized in manufacturing and exporting of qualified precision micro shafts.
Q: What are your usual terms of payment?
A: We generally ask for payment by T/T in advance and L/C at sight.
