Sage by Heston Blumenthal The Breville Scraper Beater Mixer

Discover the innovative Sage by Heston Blumenthal Breville Scraper Beater Mixer at our factory. Explore advanced features for superior mixing performance.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
FME
Layout Type
Horizontal
Mixing Drum Shape
Conical
Operating type
Cycle Operating
Condition
New
Name
Bem430sil Bowl Scraper Sage Scraper Mix
Function
Mixing, Homogenzer, Heating, Cooling and etc.
Materials
Stainless Steel
Homogenzer Speed
0-3600r/Min
Mixer Speed
0-65r/Min
Heating Way
Steam Heater / Electrice Heater
Power
0.75-15kw
Transport Package
Standard Wooden Case
Specification
10-5000L
Trademark
FULUKE
Origin
China
HS Code
8422303090
Production Capacity
20-50PCS /Month

Product Description

Sage by heston blumenthal the  breville scraper beater mixer (We also have the liquid mixing mahcine , filling machine ,capping machine atc production line for cosmetics, chemical)
Sage by Heston Blumenthal The Breville Scraper Beater Mixer

What products do u do ?
How many liter machine u need? Offer sheet in detail will be provided by below contact
Att : Manman Zhong


Sage by Heston Blumenthal The Breville Scraper Beater Mixer

500l bottom entry homogenizer mixer Application
This machine is Conform to the requirements of the GMP .It's suitable for making cream, milk liquid , cosmetics , shampoo , liquid wash etc.

500l bottom entry homogenizer mixer Main System
Main pot, water pot, oil pot, mixing homogenizing system, lift system, vacuum system, electrical apparatus control system etc.

500l bottom entry homogenizer mixer Technical Parameters
Model Effective
capacity
Homogenizer motor Stir motor Vacuum pump Heating power
kW r/min kW r/min kW Limit vacuum Electric heating Steam heating
FMB-10 10 0.55 0-3600 0.37 0-85 0.37 -0.09 6 2
FMB-20 20 0.75 0-3600 0.37 0-85 0.37 -0.09 9 3
FMB-50 50 2.2 0-3600 0.75 0-80 0.75 -0.09 12 4
FMB-100 100 4 0-3600 1.5 0-75 1.5 -0.09 24 9
FMB-200 200 4 0-3600 1.5 0-75 1.5 -0.09 24 9
FME-200 200 5.5 0-3300 1.5 0-65 2.2 -0.09 28 10
FME-300 300 5.5 0-3300 2.2 0-65 2.2 -0.085 32 12
FME-500 500 7.5 0-3300 4 0-60 4 -0.085 50 16
FME-800 800 11 0-3300 5.5 0-60 4 -0.08 65 25
FMH-500 500 7.5 0-3300 4 0-60 4 -0.085 32 12
FMH-1000 1000 11 0-3300 5.5 0-60 4 -0.08 65 25
FMD-2000 1000 11 1400-3000 5.5 0-60 4 -0.08 65 25
FMD-3000 2000 15 1400-3000 5.5 0-60 5.5 -0.08 72 43
FMD-5000 5000 22 1400-3000 11 0-60 7.5 -0.08 90 63
 ...
(The parameters are for reference only,the product depend on actual items.)


Flow Chart 500l bottom entry homogenizer mixer
Sage by Heston Blumenthal The Breville Scraper Beater Mixer

500l bottom entry homogenizer mixer  Profile

1. Vacuum emulsifier mixer is specially designed adopting advanced technology of oversea accordingto the cosmetic cream and ointment production technology.
2. The machine is made up of pretreatment boiler, vacuum emulsification blending boiler, vacuum pump hydraulic system, pouring-out system, electro control system and workable.
3. The function of the machine including mixing, homogenizing, heating, emulsifier etc. It's the best choose for making high grade cosmetic cream, lotion and can hight viscosity paste etc.

500l bottom entry homogenizer mixer Configuration

Frequency speed control Siemens
Motor Siemens / ABB
Inner material Japan SUS 316L
Control box Schneider
Upper/ bottom homogenizer
heating steam / electric
Touch PCL control Siemens


In order give you best suggestion, need you comfirm the detail information as following,

1. What is your made products? Show us picture.

2. Capacity?

3. Heating method steam or electric (the electric heating, temperature can arrive to 100degrees, the steam heating temperature can arrive to 170degrees)

4. With the oil and water phase boiler? (the oil and the water phase boiler have the heating, stiring function)

5. With homogenizer? Do you need the upper homogenizer or bottom homogenizer?

6. Buttom control or PLC touch sreem control, seimens?


Welcome to got more information (video, picture etc) CE certification(our showroom and fatory will show you, Pls contact with us )

FMB
Sage by Heston Blumenthal The Breville Scraper Beater Mixer
FME
Sage by Heston Blumenthal The Breville Scraper Beater Mixer
FMH
Sage by Heston Blumenthal The Breville Scraper Beater Mixer

FMD
Sage by Heston Blumenthal The Breville Scraper Beater Mixer
FMC
Sage by Heston Blumenthal The Breville Scraper Beater Mixer


Customer from all over the wold factory

Sage by Heston Blumenthal The Breville Scraper Beater Mixer

500l bottom entry homogenizer mixer Package & Shipping

Package  stand wooden case
Delivery time  20-40days by sea shipping / air fright




Sage by Heston Blumenthal The Breville Scraper Beater Mixer


500l bottom entry homogenizer mixer Fatory & Company
Guangzhou FULUKE Cosmetics Co., Ltd. Mainly for cosmetic machine for skin ,washing hand equipment to research and development, production, sales and service of integrated company. We are based on Yangzhou AIK Chemical Equipment Co., Ltd. for a total production ,There are excellent chemical equipment manufacturing R & D team and high-end processing equipment .and absorbing the international advanced experience in chemical manufacturing equipment, Continue to strengthen the development and management of the company's internal technology. After 10 years of development, we already own homogenizing core technology and combined with sophisticated production technology and perfect quality management system that create a series of quality and stability of emulsification equipment, and constantly praised by customers and create a good reputation ,according for market demand , we will developed in the next batch with progressive cosmetics machine design team to produce a series of equipment, such as vacuum emulsification equipment, multifunctional reaction mixing tank, filling machines, water treatment equipment for better sales and services in many well-known Cosmetic foreign manufacturers.
Sage by Heston Blumenthal The Breville Scraper Beater Mixer

Vacuum Emulsifying Machine Contact Way
Wanly welcome you come to our company or factory check the machine
Att: Manman Zhong
